S 625
Compact and economic CNC for shearing machines and simple press brakes.
Equipped with a 7” touch screen makes all operations on the machine simpler and intuitive.
Can manage up 3 axes and 16+ 12 I/O with an integrated PLC.
Storage of thousands of part programs.
All kind of shearing technology supported.
All press brake technology are managed within the limit of axes and i/o.
TYPICAL APPLICATIONS
- Conventional press-brakes (Mechanical and Hydraulic), Synchro Hydraulic Press-brakes, Servo controlled hydraulic single cylinder press-brakes
- Hydro-mechanical press-brakes American style
- Guillotine shears, with 1-3 axes
BASIC UNIT EQUIPPED WITH DIMM PC CPU AMD SX-800-
500MHz, 32MB DRAM INCLUDING
- 7” colour touch screen resolution 800×480
- 128 MB Silicon Disk.
- 3 fast counting circuits for Line Drive 0-5Vdc differential encoders or NPN/Push pull. The encoders are powered at 5Vdc (max 200mAper channel).
- 3 analog outputs(±10V) with 15bits + sign resolution.
- 2 analog inputs, 12 bits resolution.
- 2 general purposes analog outputs, 0÷10V (8 bits resolution).
- 16 digital inputs (24Vdc).
- 16 digital outputs (24Vdc, 0,7A max.) protected against overload and short-circuits.
- 1 serial ports RS232
- 1 CAN port with 9 pins SubD F connector.
- 24Vdc power supply.
- 1 USB port.
